Chipset
Intel B560 Chipset
Dimensions (inches)
8.1x15.6x16.2 (WxDxH)
Cooling system
65W Airflow
M.2 SSD DECO Mylar Heatsink
2x Front for Airflow with ARGB
1x Rear for Airflow with ARGB
Processor thread count
12
Model
Intel Core i5-11500
Accessories included
USB Calliope Keyboard
USB Calliope Mouse
RGB lighting
Legion OY Iconic LED
Internal Ambient Lighting
Model
NVIDIA GeForce GTX 1660 SUPER 6GB GDDR6
Audio details
High Definition (HD) Audio
Realtek ALC887 codec
Hard drive capacity
512GB M.2 2280 PCIe 4.0x4 NVMe SSD
1TB 7200rpm 3.5-inch HDD
Storage support
Up to five drives:
2x 3.5-inch HDD + 2x M.2 SSD + 1x open 2.5 HDD Bay
3.5-inch HDD up to 2TB each
M.2 SSD up to 1TB each
3.5mm audio output
Top:
1x headphone jack
Rear:
3x audio out (5.1 channel)
I/O expansion
1x PCIe 4.0 x16
1x PCIe 3.0 x4
3x M.2 slots (1x WLAN, 2x for SSD)
USB port
Top:
2x USB Type-A 3.2 Gen 1
Rear:
1x USB-C 3.2 Gen 2 with data transfer support and 5V 3A charging
2x USB Type-A 2.0
2x USB Type-A 3.2 Gen 1
